| # Jaws | 3 | 3 |
| Type of Actuation | Hydraulic | Hydraulic |
| Body Diameter | 8" | 203.2 mm |
| Body Height | 3.5" | 88.9 mm |
| Through Hole Diameter | 2.59" | 65.786 mm |
| Spindle Mount Type | A2-6 | A2-6 |
| Jaw Stroke | 0.288" | 7.3152 mm |
| Max Speed | 5,000 RPM | 5,000 RPM |
| Max Pull Force | 8,183 lbf | 36.4 kN |
| Max Grip Force | 19,558.4 lbf | 87 kN |
| Min Grip | 0.91" | 23.114 mm |
| Max Grip | 8.27" | 210.06 mm |
| Dimensions | 9" x 9" x 5" | 9" x 9" x 5" |
| Weight | 55 lbs | 55 lbs |
Thread Pitch: 2.0
CONDITION: This Chuck is in Like New Condition, Never Used !
F.O.B. Cincinnati, OH
