OSP-E100L CNC Control, 8000 RPM Spindle, 213 PSI High Pressure Coolant System, Chip Conveyor & Coolant Tank.
| CNC Control | OSP-E100L CNC | OSP-E100L CNC |
| # Axis | 3 | 3 |
| Table-L | 48" | 1,219.2 mm |
| Table-W | 20.08" | 510.03 mm |
| Max Table Load Capacity | 1,500 lb | 680.4 kg |
| X-Axis (Longitudinal Travel) | 40" | 1,016 mm |
| Y-Axis (Cross Travel) | 20.11" | 510.79 mm |
| Z-Axis (Vertical Travel) | 17.72" | 450.09 mm |
| Max Clearance Tabletop to Spindle Nose | 24" | 609.6 mm |
| Min Clearance Tabletop to Spindle Nose | 6.3" | 160.02 mm |
| Feed Rates (X, Y, & Z Axis) | 1,181 in/min. | 30 m/min. |
| X-Axis Rapid Traverse Rate | 1,417 in/min. | 36 m/min. |
| Y-Axis Rapid Traverse Rate | 1,417 in/min. | 36 m/min. |
| Z-Axis Rapid Traverse Rate | 1,181 in/min. | 30 m/min. |
| Spindle Power | 20 hp | 14.9 kW |
| Spindle Speed Range | 40 - 8,000 RPM | 8,000 RPM |
| Spindle Taper | 40 | 40 |
| Automatic Tool Changer Capacity (ATC) | 20 | 20 |
| Electrics | 220/3/60 | 220/3/60 |
| Dimensions | 114" x 95" x 99" | 114" x 95" x 99" |
| Weight | 16,000 LBS | 16,000 LBS |
CONDITION: This Machine Appears to be in Excellent Condition !
F.O.B. Cincinnati, OH
