1994 GIDDINGS & LEWIS 18U NUMERILATHE

GIDDINGS & LEWIS 18U X 132", G & L 8000 CNC

Giddings & Lewis 8000 CNC Control with CRT, Heavy Duty Bed Mounted Tailstock, Backlash Compensation, Hardened & Ground Slant Bed Ways, Inch/Metric Threading, 16" 3-Jaw Chuck, Steady Rest, Load Meter, Threadcutting, Chip Conveyor, Coolant System.

SPECIFICATIONS:
Max Swing Over the Slant Bed ........................... 34"
Max Swing Over Carriage ................................ 29"
Max Unrestricted Swing Between Centers ................. 132"
Max Tailstock Position ................................. 137"
Cross Travel (X-Axis) .................................. 28.5"
Longitudinal Travel (Z-Axis) ........................... 1403.5"
Tool Positions (6 ID Turret & 6 OD Turret).............. 14 Total
Spindle Bore ........................................... 5.1"
Spindle Nose ........................................... A2-11
Spindle Speed Range .................................... 5-2600 RPM
Spindle Drive Motor .................................... 50 HP

Condition: Machine Appears To Be in Excellent Condition !
